This is a highly specialized and efficient exhaust gas treatment device, considered an advanced and superior application of the flushing tower. It not only absorbs pollutants into a liquid, but also achieves pollutant reduction and resource recovery, offering significant economic and environmental advantages.
The FRP concentrator, also known as the wet pre-treatment/post-treatment unit of a rotary concentrator system, or simply the tower equipment within an exhaust gas concentration system, serves as a key component in zeolite rotary concentrator or activated carbon concentrator systems.
The fiberglass concentration tower is another application of the composite manufacturing technology behind Weitong FRP's FRP Storage Tanks line, engineered for a different purpose than storage or gas washing. Rather than absorbing pollutants into a spray liquid the way a fiberglass flushing tower does, a fiberglass concentration tower works as a dry-process pretreatment unit that protects and supports a rotary VOC concentration system, reducing a large volume of low-concentration waste gas into a small, highly concentrated stream ready for efficient destruction or recovery.
For clarity, let's use the typical "zeolite rotary concentrator + combustion" system as an example to explain the role of the FRP concentrator:
Why is FRP widely used in concentrator systems?
The reasons are similar to those for flushing towers, but with higher requirements:
Excellent Corrosion Resistance (Core Reason)
FRP provides comprehensive protection against both acidic and alkaline dust in pre-treatment and potentially corrosive combustion products (such as SO₃ forming sulfuric acid) in post-treatment.
Low surface energy, resists adhesion.
The smooth interior resists the adhesion of resin and sticky contaminants, reducing clogging and cleaning issues.
Heat resistance and dimensional stability.
Although it doesn't come into direct contact with the hottest combustion gases, the excellent resin system can withstand temperature fluctuations during pretreatment and processing.
Lightweight, high-strength, and easy to mold.
Large towers and custom shapes can be manufactured to accommodate complex project layouts.
Key Features and Advantages (as part of a system)
Protects core assets
As a pretreatment tower, it effectively protects expensive zeolite rotors or activated carbon, extending their service life and ensuring the long-term, stable operation of the entire concentration system.
Reduces waste gas volume
It works with the rotor to convert high-volume, low-concentration waste gas into low-volume, high-concentration waste gas, significantly reducing the size and energy consumption of subsequent combustion treatment equipment. This achieves the "small furnace achieves big results" effect, resulting in high economic efficiency.
Highly efficient purification
When used as an absorption tower to treat specific pollutants, it can directly and efficiently remove the target substances.
High system integration
FRP towers can be easily integrated with pipelines, pumps, water tanks, and other components to form a complete treatment unit.
A fiberglass concentration tower is a specialized FRP vessel built to serve as the pretreatment and housing stage of a zeolite rotor concentrator system. Its working sequence typically follows three stages:
Pretreatment — the tower first removes particulate matter and adjusts humidity in the incoming waste gas stream, protecting the delicate zeolite rotor or activated carbon media downstream from clogging or premature degradation
Concentration — the cleaned, dilute gas passes through the slowly rotating zeolite rotor, where VOCs are adsorbed onto the media
Desorption — a small stream of heated air passes through a separate zone of the rotor, releasing the adsorbed VOCs as a low-volume, highly concentrated gas stream suitable for thermal or catalytic destruction, or for solvent recovery
This sequence allows facilities to treat large air volumes without building oversized combustion or oxidation equipment, since only the concentrated output stream requires final treatment.
Fiberglass construction addresses the specific conditions a concentration tower must withstand on both the intake and treated-gas sides of the process:
Corrosion resistance across both stages — protects against acidic or alkaline dust during pretreatment as well as potentially corrosive combustion byproducts, such as sulfuric acid formed from SO₃, on the treated side
Low surface energy, resistant to buildup — the smooth interior wall reduces the likelihood of resin or sticky contaminants adhering, lowering the frequency of clogging and cleaning
Temperature stability — an appropriately selected resin system maintains dimensional stability through the temperature fluctuations involved in pretreatment and processing
Lightweight, moldable into large or non-standard shapes — supports the complex tower geometries required to fit into an existing plant's process layout
A fiberglass concentration tower should not be evaluated as a standalone device, but as a functional module within a larger VOC abatement system:
Protects core equipment — as the pretreatment stage, it shields the zeolite rotor or activated carbon media from particulates and corrosive substances that would otherwise shorten their service life
Reduces waste gas volume for economical treatment — combined with the rotor, it converts large-volume, low-concentration exhaust into a small-volume, high-concentration stream, significantly reducing the size and energy consumption of downstream combustion equipment
Supports system integration — an FRP concentration tower can be readily integrated with ducting, pumps, and auxiliary tanks to form a complete treatment unit alongside other Weitong FRP products
To ensure long-term, trouble-free operation, several factors should be confirmed before finalizing a fiberglass concentration tower design:
● The tower's size, internal structure, and resin selection must match the specific chemical composition of your exhaust stream and the overall process flow
● Resin type should be selected based on the actual acids, alkalis, or solvents present to avoid premature material aging
● Operating temperature range and chemical compatibility limits should be confirmed against the specific VOCs being treated
● Heavy particulate loads may require additional pre-filtration ahead of the tower to prevent clogging of the rotor or downstream media
Hebei Weitong FRP Co., Ltd. has manufactured fiberglass reinforced plastic products since 2015, operating a 20,000-square-meter production base with 11,000 square meters of dedicated workshops. As a certified fiberglass concentration tower manufacturer holding ISO9001, ISO14001, and ISO45001 certifications, every tower we produce is verified on our high-specification pressure testing platform and cured in BPO curing ovens under the same quality controls applied across our full FRP product range.
Our FRP towers have supported qualified partners including CNPC, Sinopec, CNOOC, Huaneng Group, and Beijing Enterprises Water Group on desulfurization wastewater and zero-discharge treatment projects, and we export FRP equipment to the United States, Germany, Italy, Russia, Pakistan, South Korea, and dozens of other countries, providing full support from custom design and manufacturing through installation guidance.
To provide an accurate design recommendation, please share your waste gas volume, VOC concentration, particulate load, and existing rotor or activated carbon system details with our engineering team. Contact us to discuss your fiberglass concentration tower requirements, or explore related FRP equipment, including our fiberglass flushing tower for acid and alkali gas neutralization, and our FRP integrated prefabricated pump station for complete system integration.
Application Areas
FRP concentrators are used in all industries requiring high-volume, low-concentration VOC waste gas treatment and are essential equipment in line with current environmental protection policies:
Coating and spray coating industries: automotive, furniture, home appliance, and mobile phone case spray coating lines.
Printing and packaging industries: flexible packaging printing, tinplate printing, and canning.
Electronics industries: semiconductor cleaning and LCD manufacturing.
Chemical and pharmaceutical industries: fine chemical plants and API production.
Rubber and plastics industries: tire manufacturing and rubber vulcanization.
Summary
The FRP concentrator should not be viewed as a single piece of equipment in isolation, but rather as a key functional module within a highly efficient waste gas concentration and purification system.
Its primary role is as a "guardian"—acting as a pretreatment tower at the front end of the system, protecting the core concentrator (zeolite rotor).
In certain circumstances, it can also serve as a "terminator," directly absorbing and treating specific pollutants after concentration. Its value lies in the fact that the corrosion resistance of FRP ensures the long-term, stable, and efficient operation of the entire high-tech, high-investment concentration system, ultimately helping companies achieve ultra-low VOC emissions and reduced volume at lower operating costs. When selecting a system, its design and selection must be considered from the perspective of the entire system process.
